LF-GSDxxxYF Isolated DALI DT6 + NFC Dimmable LED Driver


  • Model

    LF-GSDxxxYF

    Parameters

    Operating voltage: 220-240Vac; 180-264Vdc

    Output power: 20-80W

    Operating Voltage Limit: 198-264Vac

    Features

    1. DALI DT6 & PUSH dimmable

    2. Support DALI Part 251, 252, 253

    3. Terminal blocks: 0° push terminals

    4. Output current, dimming curve, DALI address and other parameters set via FEIG NFC or Lifud NFC app

    5. Advanced functions: EL, corridor DIM, CLO

    6. Comply with ZHAGA book 13, 24

    7. Dim to off without afterglow; PUSH: 1kV

    8. For luminaires of protection class I

    Warranty

    5 years

    Certifications

    ENEC, CE, CB, RCM, SAA, UKCA, CCC, EL

    Applications

    Indoor office lighting, hospitality lighting, residential lighting, corridor lighting, decorative lighting, commercial lighting

Show more

Keywords:

Category:

Products

Linear drivers

LF-GSDxxxYF Isolated DALI DT6 + NFC Dimmable LED Driver
  • LF-GSDxxxYF Isolated DALI DT6 + NFC Dimmable LED Driver
  • Parameter
  • Parameter
  • Order Information
  • Data-sheet
  • Certificate
  • Model

    LF-GSDxxxYF

    Parameters

    Operating voltage: 220-240Vac; 180-264Vdc

    Output power: 20-80W

    Operating Voltage Limit: 198-264Vac

    Features

    1. DALI DT6 & PUSH dimmable

    2. Support DALI Part 251, 252, 253

    3. Terminal blocks: 0° push terminals

    4. Output current, dimming curve, DALI address and other parameters set via FEIG NFC or Lifud NFC app

    5. Advanced functions: EL, corridor DIM, CLO

    6. Comply with ZHAGA book 13, 24

    7. Dim to off without afterglow; PUSH: 1kV

    8. For luminaires of protection class I

    Warranty

    5 years

    Certifications

    ENEC, CE, CB, RCM, SAA, UKCA, CCC, EL

    Applications

    Indoor office lighting, hospitality lighting, residential lighting, corridor lighting, decorative lighting, commercial lighting

  • Model Output Power Input Voltage Output Voltage Output Current Efficiency
    (full load)
    PF (full load) Dimension (L*W*H)
    LF-GSD020YF 20 W 220-240 Vac 15-56 Vdc 150-500 mA 86% (230Vac) 0.95 (230Vac) 280*30*21 mm
    LF-GSD040YF 40 W 220-240 Vac 15-56 Vdc 500-1050 mA 89% (230Vac) 0.95 (230Vac) 280*30*21 mm
    LF-GSD060YF 60 W 220-240 Vac 15-56 Vdc 1000-1500 mA 90% (230Vac) 0.95 (230Vac) 280*30*21 mm
    LF-GSD080YF 80 W 220-240 Vac 15-56 Vdc 1400-2000 mA 91% (230Vac) 0.95 (230Vac) 360*30*21 mm
  • Model Quantity Weight Packaging Dimension (L*W*H)
    LF-GSD020YF 48 pcs/ctn 8.82 kg/ctn 310*285*155 mm
    LF-GSD040YF 48 pcs/ctn 10.07 kg/ctn 310*285*155 mm
    LF-GSD060YF 48 pcs/ctn 11.78 kg/ctn 310*285*155 mm
    LF-GSD080YF 48 pcs/ctn 13.48 kg/ctn 385*285*210 mm
  • LF-GSDxxxYF Certificate is coming soon

LF-GSD020YF Specification V1.0.pdf

Size: 1.0MB

Format: pdf

LF-GSD040YF Specification V1.0.pdf

Size: 1.1MB

Format: pdf

LF-GSD060YF Specification V1.0.pdf

Size: 1.0MB

Format: pdf

LF-GSD080YF Specification V1.0.pdf

Size: 1.0MB

Format: pdf
