LF-ACDxxxA/B/C/D Built-in Outdoor D4i NFC LED Driver
-
Model
LF-ACDxxxA/B/CD
Parameters
Operating voltage: 220-240Vac; 180-264Vdc
Output power: 40&75&120&165W
Operating voltage limit: 180-264Vac
Features
1. Support DALI-2 ext. Part 251, 252, 253
2. Output current and parameters set via NFC or Lifud Programmer
3. High AUX capability: 24Vdc, 125mA;integrated 16Vdc DALI-2 BUS power supply
4. Protective features: overtemperature, short-circuit, overload, over voltage and under voltage
5. Intelligent temperature guard via external NTC resistor
6. Input Surge Protection: L-N: 6kV; L/N-GND: 10kV
7. Comply with Zhaga Book 13,24,25
8. Suitable for Class I/II light fixtures
*A: DALI-2 version B: D4i version C: ON/OFF version D: ON/OFF with NFC version
Warranty
8 years
Certifications
ENEC, CE, CB, UKCA, RCM, SAA
Applications
Street light, flood light, wall light, shoebox light
Keywords:
Category:
Products
Products
Outdoor drivers
- Parameter
- Parameter
- Order Information
- Data Sheet
- Certificate
- Video
-
Model
LF-ACDxxxA/B/CD
Parameters
Operating voltage: 220-240Vac; 180-264Vdc
Output power: 40&75&120&165W
Operating voltage limit: 180-264Vac
Features
1. Support DALI-2 ext. Part 251, 252, 253
2. Output current and parameters set via NFC or Lifud Programmer
3. High AUX capability: 24Vdc, 125mA;integrated 16Vdc DALI-2 BUS power supply
4. Protective features: overtemperature, short-circuit, overload, over voltage and under voltage
5. Intelligent temperature guard via external NTC resistor
6. Input Surge Protection: L-N: 6kV; L/N-GND: 10kV
7. Comply with Zhaga Book 13,24,25
8. Suitable for Class I/II light fixtures
*A: DALI-2 version B: D4i version C: ON/OFF version D: ON/OFF with NFC version
Warranty
8 years
Certifications
ENEC, CE, CB, UKCA, RCM, SAA
Applications
Street light, flood light, wall light, shoebox light
-
Model Output Power Input Voltage Output Voltage Output Current Efficiency
(full load)PF (full load) Dimension (L*W*H) LF-ACD040A/B/D 40 W 220-240 Vac 17-57 Vdc 200-1050 mA 90% (230Vac) 0.95 (230Vac) 132.6*76.5*33 mm LF-ACD075A/B/C/D 75 W 220-240 Vac 35-115 Vdc 200-1050 mA 91% (230Vac) 0.97 (230Vac) 132.6*76.5*33 mm LF-ACD120A/B/D 120 W 220-240 Vac 54-220 Vdc 200-1050 mA 93% (230Vac) 0.97 (230Vac) 149.8*90*40 mm LF-ACD165A/B/D 165 W 220-240 Vac 79-236 Vdc 200-1050 mA 94% (230Vac) 0.98 (230Vac) 149.8*90*40 mm -
Model Quantity Weight Packaging Dimension (L*W*H) LF-ACD040A 12 pcs/ctn 2.984 kg/ctn 207 g/pc 328*292*98 mm LF-ACD040B 12 pcs/ctn 3.068 kg/ctn 214 g/pc 328*292*98 mm LF-ACD040D 12 pcs/ctn 2.9 kg/ctn 200 g/pc 328*292*98 mm LF-ACD075A 12 pcs/ctn 3.668 kg/ctn 264 g/pc 328*292*98 mm LF-ACD075B 12 pcs/ctn 3.812 kg/ctn 276 g/pc 328*292*98 mm LF-ACD075C 12 pcs/ctn 3.5 kg/ctn 250 g/pc 328*292*98 mm LF-ACD075D 12 pcs/ctn 3.524 kg/ctn 252 g/pc 328*292*98 mm LF-ACD120A 10 pcs/ctn 5.0 kg/ctn 438 g/pc 362*286*111 mm LF-ACD120B 10 pcs/ctn 5.14 kg/ctn 464 g/pc 362*286*111 mm LF-ACD120D 10 pcs/ctn 4.84 kg/ctn 434 g/pc 362*286*111 mm LF-ACD165A 10 pcs/ctn 5.1 kg/ctn 460 g/pc 362*286*111 mm LF-ACD165B 10 pcs/ctn 5.5 kg/ctn 500 g/pc 362*286*111 mm LF-ACD165D 10 pcs/ctn 5.3 kg/ctn 480 g/pc 362*286*111 mm -
